RGBW Starcloths

Please note: our Starcloths need to be used in conjunction with our 9 channel DMX controllers for Power & static manual control.  Should you require the cloth to twinkle, you will need to plug your lighting desk into the 9 channel DMX controller & set up a chase.

  RGBW Starcloths have recently made many appearances on many UK & South African stages and have been very well received.

Unlike the typical 3 circuit White starcloth to which everybody is accustomed. The RGBW Starcloth has 3 circuits of white plus 2 RGB colour changing circuits which allows Lighting Designers to integrate colour into their shows with a DMX512 Lighting Desk when required.

Our Starcloths are made with the highest quality LED's available and fitted with a fresnel lens to give good quality light no matter what angle you look at them from.  Each LED is encapsulated for maximum reliability and only LED free solder and high quality wire is used to manufacture the Starcloths.  The Starcloths are all fire certified as they are DFR

  Made from DFR Black Super Wool Serge and backed with lightweight black cotton sheeting

We currently have:

1 off. 4.5m x 3.6m RGBW Starcloth

2 off. 3m x 3.6m RGBW Starcloth

1 off. 4.5m x 1.5m RGBW Starcloth

1 off. 3m x 1.5m RGBW Starcloth

 This can be hung:
12m x 3.6m or 10.5m x 5m or 15m x 3m

Our RGBW LED Starcloths consist of 2 RGB circuits and 3 white circuits making a total of 5 circuits but 9 actual channels due to the fact R,G & B are their own independent channels eg:


Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 Channel 9
Red Green Blue Red Green Blue White White White
(circuit 1) (circuit 1) (circuit 1) (circuit 2) (circuit 2) (circuit 2) (circuit 3) (circuit 4) (circuit 5)


Technical Specs:
Circuits: 5
Channels(lighting desk)  9
LED Voltage:   15 Volts
LED Current:  2.6 Amps
